ABW Series – ABW10-SLP
Product Code: ABW Series - ABW10-SLP

ABW10-SLP filters are custom manufactured to meet a wide range of industrial applications, including ASME certified, seawater, high temperature, high pressure, etc. The filters are complete with Stainless Steel screens and can be set up in parallel for unlimited flow capacities.

The filter bodies are available in stainless steel and carbon steel with baked-on epoxy coating. Clean filter pressure drop with 100µ screen is less than 1psi at the rated flow of the filter.

Request a Quote for

ABW Series – ABW10-SLP

Send us the details and we will get back to you.

  • Supporting Document (Optional)
  • Max. file size: 25 MB.
  • Hidden

ABW10-SLP-  filters are custom manufactured to meet a wide range of industrial applications, including ASME certified, seawater, high temperature, high pressure, etc. The filters are complete with Stainless Steel screens and can be set up in parallel for unlimited flow capacities.

The filter bodies are available in stainless steel and carbon steel with baked-on epoxy coating. Clean filter pressure drop with 100µ screen is less than 1psi at the rated flow of the filter.

Standard Features

  • Line Sizes: 2″ – 24″
  • Flow Rate: 10 – 20,000 GPM
  • Screen Opening: 10µ – 4,000µ
  • Material: SST or Carbon Steel
  • Pressure: 40 – 150 PSI
  • Temperature to: 160°F (210°F Optional)
  • Flush Valve Size: 1″, 1.5″, & 2″
  • Flush Flow Rate: 60 – 160 GPM
  • Flush Duration: 5 – 10 Seconds
  • Flushing Volume: 5 – 30 Gallons
  • NSF Approved

Basic Functionality

Contact us to request a quote today.

Filter Model Flange Size Screen Area Max Flow Empty Weight
(mm) (m²) (m³/h) (kgs)
ABW10-SLP 250 1.16125 908 363.2
