Big Pleated High Flow Filter Cartridges
Product Code: Big Pleated High Flow Filter Cartridges

Grace Big Pleated High Flow Filter Cartridges utilize pleated depth media and result in exceptional flow capacity, low-pressure drop, and excellent retention efficiency. The considerate design of the top handle makes manual operation quick and easy. Extended service life and less maintenance requirement make the filter cartridges as one of the most cost-saving solutions in big RO applications.

Request a Quote for

Big Pleated High Flow Filter Cartridges

Send us the details and we will get back to you.

  • Supporting Document (Optional)
  • Max. file size: 50 MB.
  • Hidden

Grace Big Pleated High Flow Filter Cartridges utilize pleated depth media and result in exceptional flow capacity, low-pressure drop, and excellent retention efficiency. The considerate design of the top handle makes manual operation quick and easy. Extended service life and less maintenance requirement make the filter cartridges as one of the most cost-saving solutions in big RO applications.

  • High surface area results in longer service life, lower pressure drop and higher flow capacity.
  • The considerate design of top handle makes change out quick and easy.
  • Extended service life and less maintenance requirement make the cartridges as one of the most cost-saving solutions.
  • Available in various sizes and filter media to meet different needs and applications.
  • Free of additives and binders due to advanced thermally welding construction.




Type Polypropylene  Melt Blown Polypropylene  Fiber Pleated Glass Fiber Pleated Polyethersulfone  Pleated
Micron Rating 1, 5, 10, 20, 30,

50, 100 μm

1, 5, 10, 20, 40, 70 μm 1, 5, 10, 20 μm 0.1, 0.2, 0.5, 1 μm
O-ring Silicone, EPDM, Viton, Teflon encapsulated Viton
Core Glass Filled  Polypropylene Glass Filled  Polypropylene Glass Filled  Polypropylene Glass Filled  Polypropylene
Filter Support Polypropylene Polypropylene Polyester Polypropylene
End Cap Glass Filled  Polypropylene Glass Filled  Polypropylene Glass Filled  Polypropylene Glass Filled  Polypropylene
Cage Glass Filled  Polypropylene Glass Filled  Polypropylene Glass Filled  Polypropylene Glass Filled  Polypropylene
Inside Diameter 3″(75mm)
Outside Diameter 6″(152mm)
Polypropylene Glass Fiber Polyethersulfone
Maximum Operating Temperature 82oC (180oF) 121oC (250oF) 82oC (180oF)
Maximum Differential Pressure 3.4 bar at 82oC (50 psi at 180oF), 2.2 bar at 25oC (33 psi at 77oF)
Recommended Change Out  Differential Pressure 2.2 bar (33 psi)


Pre RO/DI, Cooling Water, Chemicals, Petrochemical, Electronics, Food & Beverage
