GDN – Nylon Membrane Pleated Filter Cartridges
Product Code: GDN - Nylon Membrane Pleated Filter Cartridges

GDN series Nylon Membrane Pleated Filter Cartridges provide superior removal efficiency, yielding the cleanest process fluids in a variety of fine filtration applications. Inherent hydrophilic Nylon membranes enquire no pre-wetting and are conveniently ready to use. With broad chemical compatibility and excellent temperature endurance, GDN cartridges are ideal options to satisfy various chemical filtration processes.

Request a Quote for

GDN – Nylon Membrane Pleated Filter Cartridges

Send us the details and we will get back to you.

  • Supporting Document (Optional)
  • Max. file size: 50 MB.
  • Hidden

GDN series Nylon Membrane Pleated Filter Cartridges provide superior removal efficiency, yielding the cleanest process fluids in a variety of fine filtration applications. Inherent hydrophilic Nylon membranes enquire no pre-wetting and are conveniently ready to use. With broad chemical compatibility and excellent temperature endurance, GDN cartridges are ideal options to satisfy various chemical filtration processes.

  • High surface area design provides excellent flow capacity and long service life while maintaining maximum filtration performance.
  • Free of additives, binders, and lubricants.
  • Wide chemical compatibility makes GDN ideal for chemical industries requiring high purity.
  • Maybe autoclaved (121 C, 30minutes cycles) or in situ steam sterilized (125 C, 30 minutes cycles) for maximum accumulated exposure of 10 hours.


Filter Media Nylon
Micron Rating 0.1, 0.2, 0.45, 1 μm
Gasket/O-ring Silicone, EPDM, Viton, Teflon encapsulated Viton
Core Polypropylene
Filter Support Polypropylene
End Cap Polypropylene
Cage Polypropylene
Outside Diameter 2.75″(70mm)
Maximum Operating Temperature 110oC (230oF)
Maximum Differential Pressure 4.8 bar at   50oC (70 psi at 122oF)
 3.4 bar at 80oC (50 psi at 176oF)
1.8 bar at 110oC (20 psi at 230oF)
Recommended Change Out Differential Pressure 2.4 bar (35 psi)


  • RO/DI Process, Semiconductor, Chemicals, Solvents, Inks, Cosmetics, Medinice Filtration, Food & Beverage
