GDP – PP Fiber Pleated Filter Cartridges
Product Code: GDP - PP Fiber Pleated Filter Cartridges

GDP series PP Fiber Filter Cartridges offer economical solutions for a variety of requirements with its excellent filtration efficiency and chemical compatibility across a wide range of liquid process applications. The construction utilizes thermal welding techniques to seal all components and therefore eliminates extracts and optimizing cartridge integrity.  Featuring an excellent retention rate and high surface area,  the GDP filter cartridges are widely recommended for demanding applications requiring high purity.

Request a Quote for

GDP – PP Fiber Pleated Filter Cartridges

Send us the details and we will get back to you.

  • Supporting Document (Optional)
  • Max. file size: 50 MB.
  • Hidden

GDP series PP Fiber Filter Cartridges offer economical solutions for a variety of requirements with their excellent filtration efficiency and chemical compatibility across a wide range of liquid process applications. The construction utilizes thermal welding techniques to seal all components and therefore eliminates extracts and optimizing cartridge integrity.  Featuring an excellent retention rate and high surface area,  the GDP filter cartridges are widely recommended for demanding applications requiring high purity.

  • High surface area design provides excellent flow capacity and long service life while maintaining maximum filtration performance.
  • Broad chemical compatibility for a wide range of liquid process applications.  Free of binders, additives, and lubricants.
  • Constructed by advanced thermal welding techniques to seal all components.
  • May be autoclaved (121 oC, 30 minutes cycles) or in situ steam sterilized (121 oC, 30 minutes cycles) for maximum accumulated exposure of 10 hours.


Filter Media Polypropylene
Micron Rating 0.2, 0.45, 1, 2, 3, 5, 10, 30, 40, 50, 70 μm
Gasket/O-ring Silicone, EPDM, Viton, Teflon encapsulated Viton
Core Polypropylene
Filter Support Polypropylene
End Cap Polypropylene
Cage Polypropylene
Outside Diameter 2.75″(70mm)
Maximum Operating Temperature 80oC (176oF)
Maximum Differential Pressure 4.8 bar at 20oC (70 psi at 68oF)
 3.4 bar at 50oC (50 psi at 122oF)
1.4 bar at 80oC (20 psi at 176oF)
Recommended Change Out Differential Pressure 2.4 bar (35 psi)


  • RO/DI Process, Ink, Etchants, Developers, Chemicals, Cosmetics, Medicine Filtration, Process Gases, Food & Beverage
