GDV – PVDF Membrane Pleated Filter Cartridges
Product Code: GDV - PVDF Membrane Pleated Filter Cartridges

GDV Membrane Pleated Filter Cartridges are constructed of hydrophobic polyvinylidene fluoride (PVDF) membranes with the advantage of extremely low protein binding, offering superior bacteria and particle removal efficiency. With a wide range of  chemical compatibility, GDV cartridges are ideal  for pharmaceutical and biological processes in less  aggressive applications.

Request a Quote for

GDV – PVDF Membrane Pleated Filter Cartridges

Send us the details and we will get back to you.

  • Supporting Document (Optional)
  • Max. file size: 50 MB.
  • Hidden

GDV Membrane Pleated Filter Cartridges are constructed of hydrophobic polyvinylidene fluoride (PVDF) membranes with the advantage of extremely low protein binding, offering superior bacteria and particle removal efficiency. With a wide range of  chemical compatibility, GDV cartridges are ideal  for pharmaceutical and biological processes in less  aggressive applications.

  • Extremely low protein binding character offers superior bacteria and particle removal efficiency.
  • Economic alternatives to all fluropolymer filter cartridges in less aggressive applications.  Satisfy various chemical processes by broad chemical compatibility.
  • 100% integrity tested and testable in situ.
  • Maybe autoclaved (121 oC, 30 minutes cycles) or in situ steam sterilized (125 oC, 30 minutes cycles) for maximum accumulated exposure of 10 hours


Filter Media PVDF
Micron Rating 0.1, 0.2, 0.45, 1 μm
Gasket/O-ring Silicone, EPDM, Viton, Teflon encapsulated Viton
Core Polypropylene
Filter Support Polypropylene
End Cap Polypropylene
Cage Polypropylene
Outside Diameter 2.7″(70mm)
Maximum Operating Temperature 100oC (212oF)
Maximum Differential Pressure 4.8 bar at   20oC (70 psi at   68oF)
 2.1 bar at 100oC (30 psi at 212oF)
Recommended Change Out Differential Pressure 2.4 bar (35 psi)


  • RO/DI Processes, Storage Tank Vents, Process Gases, Solvents, Semiconductor, Food & Beverage, Chemicals,  Pharmaceutical, Medicine Filtration
