Stainless Steel Bag Filter Housings
Stainless Steel Bag Filter Housings
Stainless Steel Bag Filter Housings are recommended as economic entry models for commercial and general filtration processes with the features of lightweight and low-pressure drop. The clamp closure and threaded coupling make closure quick and easy. The height of the housing is adjustable by the design of the mounting-legs module. Constructed by 100% stainless steel, the housings offer superior corrosion resistance for a wide range of applications while staying in consistent filtration performance.
Request a Quote for
Stainless Steel Bag Filter Housings
Send us the details and we will get back to you.
Stainless Steel Bag Filter Housings are recommended as economic entry models for commercial and general filtration processes with the features of lightweight and low-pressure drop. The clamp closure and threaded coupling make closure quick and easy. The height of the housing is adjustable by the design of the mounting-legs module. Constructed by 100% stainless steel, the housings offer superior corrosion resistance for a wide range of applications while staying in consistent filtration performance.
| Model | A | C | ØD | E | ØG | H | ØJ | ØK | L | M | N3 | Flow Rate | G .Weight | Volume |
| UFB01 | 550 | 740 | 232 | 176 | 172 | 350 | 10 | 323 | 520 | 190 | 1/4″ | 0~ 90 GPM / 0~20 m3/hr | 21kg | 27L |
| UFB02 | 1005 | 1195 | 232 | 176 | 172 | 730 | 10 | 323 | 520 | 190 | 1/4″ | 0~200 GPM / 0~45 m3/hr | 26kg | 46L |
| UFB03 | 360 | 538 | 180 | 150 | 98 | 200 | 10 | 252 | 350 | 178 | 1/4″ | 0~ 20 GPM / 0~4.5 m3/hr | 14kg | 11L |
| UFB04 | 495 | 673 | 180 | 150 | 98 | 310 | 10 | 252 | 350 | 178 | 1/4″ | 0~ 45 GPM / 0~10 m3/hr | 15KG | 14L |
UNIT: mm
Customized housings are available on request.
Actual flow rates will be determined on element selection and fluid viscosity.
| Maximum Operating Temperature | 75oC (167oF) (Base on the selection of filter element and O-ring material.) |
| Maximum Operating Pressure | 7 bar at 75oC (100 psi at 167oF) |
Inks & Polymers Filtration, Paints & Lacquer Filtration, Chemicals, Petrochemicals, Electronics, Waste Water Treatment, Food & Beverage, Pharmaceuticals, Pre RO/DI
